Model KRZ series is widely applied to phosphate ester fire-resistant oil system, EH Fluids system, Reolube system, etc. It applies for online maintenance of the fire resistant oil for turbine system, filtering and purifying as well as regeneration of related hydraulic system.
Features:
1). The purifier KRZ is a next-generation vacuum oil purifier destined for phosphate ester fire-resistant oil system, utilizing dewatering and degassing technologies such as anti-precipitation, aggregation, separation transformation, resolution, vacuum entrapment and flash evaporation, which not only speedily removes the free water in oil but also intensively removes the dissolved water and gas in oil.
2). The stage-to-stage dandified filter element made of new composite materials can remove the large amount of impurities in oil and results in a precision filtration.
3). Application of new absorptive materials can effectively absorb the jelly substance in oil, and eliminate the acid content in oil, as well as inhibiting the production of new acid in the system.
4). The purifier body is made of acid and dissolving resistant stainless steel; filter element and seal are made of materials, which are compatible with fire-resistant oil.
Technical Parameters:
Name |
Unit |
KRZ |
Flow |
L/min |
20 ~ 500 |
Total Power |
KW |
7.5 ~ 74 |
Power Supply |
  220V/380V/415V/440V/470V, etc. |
|
Operating Temperature |
℃ |
≤ 70 |
Working Noise |
dB(A) |
≤ 65 ~ 80 |
Water Content |
PPM |
≤ 5 |
Gas Content |
% |
≤ 0.1 |
Cleanliness |
NAS1638 |
≤ 5 (MOOG1 Grade) |
Acid Value |
MgKOH/g |
≤ 0.05 |
Color |
Transparent (ASTM D1.5 or better) |
|
Resistant |
Ω |
≥ 5.0 × 109 |
Chloricle Content |
% |
≤ 0.005 |
**For more precise details, please contact CTBU Sales.
